model

SCP

SCR

SWP

SRM-RMC

SWM-WMC

 Contact configuration

2N/C+1N/O

2N/C+1N/O

2N/C

1NC+1N/O

1N/C

2N/C+1N/O

2N/C+1N/O

Explanation

Multiple selection modes

 SCR-022

(24 VAC/DC)

2N/C

2M

 SCR-025

(24 VAC/DC)

2N/C

5M

 SCR-0210

(24 VAC/DC)

2N/C

10M

 SCR-0221

(24 VAC/DC)

2N/C+1N/0

2M

 SCR-0251

(24 VAC/DC)

2N/O+1N/C

5M

 SCR-0211

(24 VAC/DC)

2N/O+1N/C

10M

 SCR-012

(230 VAC)

1N/C

2M

 SCR-015

(230 VAC)

1N/C

5M

 SCR-0110

(230 VAC)

1N/C

10M

 SCR-012

(230 VAC)

1N/C+1N/O

2M

 SCR-015

(230 VAC)

1N/C+1N/O

5M

 SCR-0110

(230 VAC)

1N/C+1N/O

10M

 Remarks

Mechanical reliability: B10d

3.3 x 106 running ISO13849-1 under 100mA load, according to system architecture, up to Ple

EN62061 to SIL3 depends on the system architecture

Safety data

8 times per year / 24 hours a day / 365 days Full HD 2.52 x 10-8

 MTTFD

(Life) 47 years MTTFD470 years

Safe channel 1 NC

250Vac 2.0A maximum rating

Safe channel 2 NC

250Vac 2.0A maximum rating

Safe channel 3 NC

Maximum rating 24Vdc 0.2A

 Contact release time

<2ms

 Minimum switching current

10Vdc 1mA

Main material

Certified polyester

 Operating temperature

-25C+80C

Enclosure rating

IP69K（NEMA PW12）IP67（NEMA 6）

Impact resistance

IEC68-2-27 11ms 30g

Vibration resistance

IEC68-2-6 10-55Hz 1mm

Cable type

PVC 6 core 6mm OD conductor 0.25mm2

 Safety Relays

SR103 series

1 set of security products

3N/O+1N/C

See product information for details

Safety Relays

SR301 series

3 set of security products

2N/O

Safety Relays

SM601 series

6 groups of safety products

2N/O+4Tr
